Prodec Products |
|
|
Level
Dec |
|
| |
|
What is the
Level Dec?
Put simply, the level dec is a superior preformed level access shower base that when set into the floor can either be
completely covered with non-slip flooring or tiled to provide a step free and unrestricted shower area.
|
Why choose Level-Dec?
Durable, extremely strong and light weight to install. Engineered for
maximum performance, For timber or floating floors Saves creating difficult gradients, Saves labour and cost effective. Its 22mm thick to finishes flush with the existing floor. 17mm preformed gradient on all sizes. Drain positions designed to avoid joists, Suits most
proprietary vinyl flooring, i.e Tarkett, Altro, Tarasafe, Marley etc. Accepts
level dec screens and is waste pump compatible. |
|
How To Install?
The level dec being 22mm thick is ideal for most timber and first floor situations. To fit the dec the floor boards are removed. When the drainage and the pipe work have been installed the dec can then be permanently fixed to the joists. The remaining floor must finish level with the decs edges in preparation for the non slip vinyl floor covering.
|
Completed
level dec : |
|
|
|
|
|
|
|
|
|
| |
Harmer
Drain |
|
|
| |
|
What is a Harmer Drain?
The Harmer drains is basically a ground floor version of the
level dec. The existing screeded floor gets removed and a new floor is screeded with
at least 17mm gradient. This also provides a step free finish. |
Why Choose the Harmer Drain?
Harmer Shower drains are as good looking as they are efficient. Tile grate kits are used in tiled floor applications. The top surface of the bell component is available with a non-slip dimpled
finish. Tile grates are all available in
a choice of colours. High-flow performance,
Elegantly un-intrusive design. Suitable for different types of floor finish including tiles and flexible sheet. Low maintenance and self cleansing. Pump Compatible.
|
|
How To Install?
To Install the Harmer Drain you must firstly hack up the existing screed to the required shower area.
Drainage or pumped system must then be installed before relaying a new floor that must be sloping into the drain to allow the water to run away
freely. This is then completely covered with vinyl flooring to give a unrestricted step free shower area.
|
Completed
Harmer Drain : |
|
|
|
|
|
|
|
|
|
| |
Sit
On Trays |
|
|
| |
|
What is a Sit On Tray?
The Sit On Tray has been professionally designed to provide comfortable access when entering or exiting the shower. The high specification means that these trays are extremely strong and self
supporting, The trays are made of Glass Reinforced Plastic and are only 35mm in depth. The nature of the tray also allows them to be set in to the floor. |
Why Choose The Sit On Tray?
They are Only 35mm high and Can be set in to floor for level access. Self supporting. Not handed, Separate tiling strip. Trap should avoid joists, Solos trap 50mm water seal. If the floor can not be breached there are ramps available. Waste pump compatible Suits
level dec carer screens Cut to length tray, to suit your space. |
|
How To Install?
Possibly the easiest of the 3 the sit on tray dose exactly what it say sits on the floor, so after removing the bath its a simple case of
bedding the tray to the floor and checking you have the correct falls.
Screens and additional ramps can be fitted 24 hours after the tray has been bedded. The rest of the bathroom floor is then finished with non slip vinyl floor covering.
|
Completed
Sit On Trays : |
|
|
|
|
|
|
|
|
|
|
|
|
|
